Optimized for high-temperature industrial chemical processes in strong acids and alkalis, this refillable, high-strength cylindrical glass probe utilizes a porous ceramic sand core to deliver a highly stable liquid interface.
| Sensor Model | ASP220EHF |
| Digital or Analog | Analog |
| Measuring Principle | Potentiometric |
| Measuring Parameter | pH |
| Measuring Range | pH 0~14 |
| Indicator Electrode | Cylindrical glass membrane |
| Reference System | Ag/AgCl reference electrode, Double salt bridge |
| Electrode Material | Glass+porous ceramic sand core |
| Temp.&Pressure | 0~135℃@6Bar |
| Sample Flow Rate | 0.5 m/s ≥ velocity ≥ 0.001 m/s |
| Zero Position(E0) | ±0.25pH (25℃) |
| Slope% | >95% (25℃) |
| Temperature Unit | @customized PT1000, PT100, NTC10K, etc. |
| Sensor Dimension | Diameter: 12mm, Shaft length: 120mm |
| Mounting Thread | PG13.5 |
| Lead Type | Integrated or split FS8, K8S, FVP, etc. (@optional) |
| Cable Length | 5m as standard (Customizable length available) |
| Application | Strong acid and alkali |
| Model Family | ASP400 |
